Ultrasonic cleaning + rinsing + drying

1.Place the parts in the first tank for ultrasonic cleaning with a filtration system. The cleaning solution consists of tap water and detergent, and the cleaning time is approximately 10-15 minutes.
2.After 15 minutes, transfer the parts to the second tank for rinsing to remove the cleaning agent and residual stains, ensuring a better cleaning effect. The rinsing medium is only tap water, and the parts should soak in the second tank for about 5 minutes.
3.For the final step, place the parts in the drying tank for 5-10 minutes.

Request Quote Download

Product Features

01

Fast and thoroughly cleaning
02

Saving labor, time, detergent
03

OEM/ODM wholesale service
04

No damage for cleaning the parts
05

Removing dirt and dust easily
06

With emergency stop switch
07

SUS 304/SUS 316 tank material
08

Filtration system to filter floating debris
09

Powerful and durable branded pumps
10

Free stainless steel cleaning basket
11

With water inlet/outlet in suitable place
12

With stainless steel basket
13

Double/Multi frequency is available

Technical Parameter

Model	Capacity (L)	Tank Size (mm)	Ultrasonic Power (W)	Hetaing Power(W)	Drying Heating Power(W)	Frequency (kHz)	Timer (Min/H)	Temperature (°c)	Drying Temperature (°c)
JP-3024GH	38L	500300250mm	0-600W	1500W	3000W	28/40	0-99MIN	Room temp-95	Room temp-150
JP-3036GH	53L	500350300mm	0-900W	1500W	3000W	28/40	0-99MIN	Room temp-95	Room temp-150
JP-3048GH	77L	550400350mm	0-1200W	3000W	3000W	28/40	0-99MIN	Room temp-95	Room temp-150
JP-3060GH	99L	550450400mm	0-1500W	3000W	4500W	28/40	0-99MIN	Room temp-95	Room temp-150
JP-3062GH	96L	800300400mm	0-1500W	3000W	4500W	28/40	0-99MIN	Room temp-95	Room temp-150
JP-3072GH	135L	600500450mm	0-1800W	4500W	4500W	28/40	0-99H	Room temp-95	Room temp-150
JP-3096GH	175L	700500500mm	0-2400W	6000W	6000W	28/40	0-99H	Room temp-95	Room temp-150
JP-3120GH	264L	800600550mm	0-3000W	6000W	6000W	28/40	0-99H	Room temp-95	Room temp-150
JP-3144GH	360L	1000600600mm	0-3600W	9000W	6000W	28/40	0-99H	Room temp-95	Room temp-150
JP-3168GH	420L	1500700400mm	0-4200W	12000W	6000W	28/40	0-99H	Room temp-95	Room temp-150
JP-3192GH	480L	1200500800mm	0-4800W	12000W	9000W	28/40	0-99H	Room temp-95	Room temp-150
JP-3216GH	540L	1000900600mm	0-5400W	18000W	9000W	28/40	0-99H	Room temp-95	Room temp-150
JP-3240GH	640L	1000800800mm	0-6000W	18000W	9000W	28/40	0-99H	Room temp-95	Room temp-150
JP-3264GH	800L	10001000800mm	0-6600W	24000W	12000W	28/40	0-99H	Room temp-95	Room temp-150
JP-3288GH	960L	12001000800mm	0-7200W	24000W	12000W	28/40	0-99H	Room temp-95	Room temp-150
JP-3432GH	1500L	150010001000mm	0-10800W	30000W	15000W	28/40	0-99H	Room temp-95	Room temp-150

Related videos

Car workshop, diesel workshop, car industry, scientific laboratory, university, dental clinics, eyeglass shop, hardware tools shop, Jewelry industry, medical industry, electronic factory, molding factory,

Cleaning Effect

Ultrasonic cleaning provides a quick and efficient way to remove oil, grease, rust, glue, and other debris. It also excels at cleaning blind holes, narrow slits, and hard-to-reach areas on workpieces, ensuring thorough results.
